Motion Raceworks SBF Engine Diaper for Dual Sump for Moroso 20534 / 20520 and similar Oil Pan

Motion Raceworks SBF Diaper for Dual Sump for Moroso 20534 / 20520 and similar Oil Pans

As the most popular oil pan for the SBF platform, we wanted to make a diaper that covers all of the bases for our customers.  Our LS and Mod Motor Diapers have been a huge hit in the past so we took the ingredients and designed something for this platform.

This Diaper Comes with everything needed for installation.

Features include:

• Quick Disconnect Vertical Straps for easy Oil Change/Service
• High Quality Stainless Steel brackets to attach to heads/header flange
• Standard Kevlar Strapping in high heat areas to resist melting
• Horizontal bottom strapping to pull any excess slack from critical areas
• Quick Disconnect Motor Mount straps to allow installation/removal in car with motor mounts w/ Kevlar strapping as it is near exhaust
• Optimized Header Brackets to allow for spark plug / boot clearance.
• Sides are designed to allow for routing of oil lines (loose until tensioning straps)
• Ballistic Nylon Main Body
• Replaceable Absorbable insert
• Cutout for Oil Filter
• NHRA / IHRA approved
• Made in the USA

*Note: Engine Diaper is not made to make direct contact with exhaust or turbo headers and other high heat sources.  We offer no warranty if comes into contact with these.

*Note: Please insure and take care to make proper clearance for flexplate and other moving items when installing



Learn more about Engine Diapers
